Description Specifications Standard Accessories Optional Accessories
IM3590 - HIOKI Chemical Impedance Analyzer HIOKI SW1002: 12-slot switch mainframe for up to 264 channels (2-wire), switching between voltmeter and battery tester for large-scale OCV and impedance tests.
Key Capabilities Switch between voltmeter and battery tester while testing SW1002: max. 264 channels (2-wire) to max. 72 channels (4-terminal pair) Circuit-design-friendly for impedance measurements that minimize errors between channels (Effect: 0.01% f.s. [*1]) For OCV measurement, internal resistance measurement, and external potential measurement of battery cells Measure battery modules up to 60 V DC *1: For BT4560 100 mΩ range, R measurements, and a measurement frequency of 1 kHz Contact RCC Electronics for Canadian availability, configuration guidance and a formal quotation.
Technical Specifications Slots 12 slots Supported modules MULTIPLEXER MODULE SW9001 (2-wire/4-wire); MULTIPLEXER MODULE SW9002 (4-terminal pair) Connectible instruments Max. 2 units; 2-wire × 1 + 4-wire × 1, or 2-wire × 1 + 4-terminal pair × 1 Max. input voltage 60 V DC (Cannot connect to battery packs in excess of 60 V DC), 30 V AC rms, 42.4 V peak, Maximum rated voltage to ground: 60 V DC Communication I/F LAN, USB, RS-232C (for host, for measurement instruments) Functions Channel switching, wiring method, scan function, communication command transmission, channel delay, shield switching Power supply 100 to 240 V AC / 30 VA (50/60 Hz) Dimensions and mass 430 mm (16.93 in) W × 132 mm (5.20 in) H × 420 mm (16.54 in) D, 6.0 kg (211.6 oz) SW9001 SW9002 Wiring method 2-wire or 4-wire; 4-terminal pair (6-wire) or 2-wire No. of channels 22 channels (2-wire) / 11 channels (4-wire); 6 channels (4-terminal pair) / 6 channels (2-wire) Contact method Armature relays Channel switching time 11 ms (excluding measurement time) Max. allowable voltage 60 V DC, 30 V AC rms, 42.4 V peak Max. allowable current 1 A DC, 1 A AC rms; 1 A DC, 1 A AC rms (Sense), 2 A DC, 2 A AC rms (Source, Return) Max. allowable power 30 W (resistive load) Maximum rated voltage to ground 60 V DC Dimensions and mass 25.5 mm (1.00 in) W × 110 mm (4.33 in) H × 257 mm (10.12 in) D, 210 g (7.4 oz); 25.5 mm (1.00 in) W × 110 mm (4.33 in) H × 257 mm (10.12 in) D, 196 g (6.9 oz)
Official HIOKI product information
Standard Accessories Optional accessories below are not included unless stated on the RCCE quotation.
Optional Accessories MULTIPLEXER MODULE SW9001 MULTIPLEXER MODULE SW9002 CONNECTION CABLE L2004 CONNECTION CABLE L2108 CONNECTION CABLE SET L4930 USB CABLE (A-B) L1002 RS-232C CABLE 9637 LAN CABLE 9642 BATTERY HiTESTER BT3561A — • Resistance ranges: 30 mΩ/300 mΩ/3 Ω/30 Ω/300 Ω/3 kΩ; • Voltage ranges: 6 V/60 VBATTERY HiTESTER BT3562 — • AC, 1kHz testing source; • 6 to 60 DC V, 10 μV resolution, ±0.01% accuracy; • 3mΩ to 3000Ω rangeBATTERY HiTESTER BT3562A — • Resistance measurement ranges: 3 mΩ/30 mΩ/300 mΩ/3 Ω/30 Ω/300 Ω/3 kΩ; • Voltage measurement ranges: 6 V/60 V/100 VBATTERY IMPEDANCE METER BT4560-50 — • Reliable EIS measurement of high-capacity batteries for EVs & ESSs; • EIS measurement frequency: 0.01 Hz to 1 kHz; • Impedance: max. resolution 0.1 µΩPRECISION DC VOLTMETER DM7276 — • 100mV to 1000V DC, 7-1/2 digit resolution; • 9ppm (±0.0009% rdg) accuracy; • DCV and temperature testingCHEMICAL IMPEDANCE ANALYZER IM3590 — • |Z|, L, C, R, σ, ε testing; • Battery testing function; • 1 mHz to 200 kHz; • 2 ms test speed, ±0.05% accuracyRESISTANCE METER RM3545 — • DC, max 1A testing source; • 2.2ms measurement speed; • 10 mΩ to 1000 MΩ range, 0.01 μΩ resolution; • Multiplexer option: 4-wire testing across 20 pointsFOOT Confirm compatibility and the final configuration with RCC Electronics before ordering.
