Rated current |
500 A rms (requires derating at frequency) |
|
Frequency band width |
DC to 2 MHz (-3 dB) |
|
Rise time |
=<35 ns |
|
Noise level |
25 mA rms max. (band width limited to 20 MHz) |
|
Accuracy (DC or 45 to 66 Hz) |
±1.0 % rdg. ±1 mV |
|
Output rate |
0.01 V/A |
|
Max. circuit voltage |
600 V CAT II 300V CAT III (insulated wire) |
|
Core jaw dia. |
Ø20 mm(0.79 in) |
|
Power supply |
±12 V ±1 V, 7.2 VA max., Plug: FFA.0S.304.CNAC42Z / LEMO inc. |
|
Dimensions, mass |
176 mm(6.93 in)W × 69 mm(2.72 in)H × 34 mm(1.34 in)D, 450 g (15.9 oz), cord length: 2 m(6.56 ft) |
|
Accessories |
Carrying case (1) |
